Thermostatic Controller Digital Factory Price DHG9140 Benchtop Small Curing Oven

Thermostatic Controller Digital Factory Price DHG9140 Benchtop Small Curing OvenProduct IntroductionSpecifications:
1. Blast drying oven
2. Advanced micro-computer control
3. Easy to operate
4. Over temp. alert
5. With Timing
6. MaunfacturerApplications:It is applicable to such tests as drying, cure melting, sterilizing in industrial and mining enterprises as well as in laboratory and scientific research institutes. Normally the oven is widely used in the fields of Electrics, Electronics, Instruments, Materials, Education, Medicine, chemical industry or other Scientific Research Organizations and Production Units.Characteristics:1.The working room is made of high quality sheet steel or corrosion-resistant stainless steel, safe and easy to use.
2. Hot air circulation system consists of low-noisy fan and optimal air duct, reaching a constant temp inside the working room.
3.Intelligent temperature controller is based on micro-processor with PID parameters controlling function. Digital display set and actual temperatures. High temp controlling accuracy and reliability.1. Unique China Streamline arc design, shell is made of cold-roll steel sheet with surface electrostatic plastic spraying; Liner is made of high quality stainless steel, and the arc corner makes it easier for cleaning.
2. MCU microcontroller technology for temperature controller system, with functions of temp controlling, timer, and over-temp alarm.
3. Reasonable air duct and circulation system, ensure the working room with good temp even rate; Adopts good performance motor and blades and also air convection breeze device, makes the air in working room can be updated and circulated.
4. Height and Number of rack in the working room can be adjusted according to customers’ requests.Technical Datas:

Model	DHG-9030A	DHG-9070A	DHG-9140A	DHG-9240A	DHG-9420A	DHG-9620A	DHG-9920A
Power Supply	220V/50HZ
Shell Material	Spray-paint Anti-corrosion
Liner Material	304 Stainless Steel
Temp. Range	RT+10~250°C					RT+10~300°C
Temp. Stability	±1.0°C
Temp. Analysis	0.1°C
Working Temp.	+5~40°C
Input Power (W)	850	1100	1550	2050	3500	4000	6000
Chamber Capacity (L)	40	72	151	216	393	672	960
Inner Dimension  (W*D*H,mm)	340*340*340	400*400*450	550*500*550	600*600*600	750*750*700	840*600*1335	1000*600*1600
Overall Dimension  (W*D*H,mm)	630*600*500	680*690*630	830*800*720	900*870*840	1050*950*920	980*800*1710	1140*800*2150
Shelves (Pcs)	1	2			3	4	5
Timer	1~9999 min
Optional Configuration	Explosion-proof  Equipment

Other Models◊ Click on each model for more specific informations↑ Packaging & ShippingShipment Safe and EfficientPackaging details: In WOODEN CASE, CARTON BOX or as your customized.
Shipping: Shipped by express,sea and air.The most suitable one could be chosen according to your budget and timeline.
Delivery detail: Within 3-7 working days after payment. Our ServicesTechnology Service1. Pre-service
24 Hours online service for your consult.
Help choose right model,and a series of service,person,advise.
2. Middle service
--Give you best offer
--Provide discount for many sets order
--Do customer's request:
--Choose payment term you convienent.
--Promptly production and delivery,inform you in time.
--Can provide invoice value as you like to decrease your tax.
3. After sale service
--1 year warranty service and all life maintenance.
--Technical Egineer are avalible for oversea trainning.
--Free change for some parts
--Remote control technical consult
--Free installation DVD
--Maintenance plan
4. Good Packaging
All products are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc.Tel: +86-371-53780197
Fax: +86-371-60920178
http://www.kdinstrument.com/ http:/// Company Information  Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd. is specialized in R & D, production, sales, teaching and chemical biology pharmacy equipment integrated company. Company tenet: keeping reputation, valuing contracts, supplying lower prices and better quality equipments to serve the cause of China's scientific research.  The company always adheres to the "quality casting brand, professional achieves service" business philosophy, and the main products are rotary evaporator, Jacketed Glass Reactor, Single Layer Glass Reactor, circulating water vacuum Pump, low temperature reaction bath (slot), low temperature cooling fluid circulating pump(cool chiller), Vacuum drying oven, blast drying oven, Freeze Dryer, water/oil bath, magnetic heating stirrer, overhead mixer, ultrasonic cleaning machine, lift platform, etc. Besides, we act as agents of some domestic and foreign famous enterprise products, sustaining high praise in domestic junior colleges and universities, scientific research units, etc. Our products are sold to USA, Australia, Asia, Brazil, Iran, Egypt etc. countries and our customers have been fully affirmation.


Buyer FeedbackOur products are very popular: FAQ1. How many shelves does your oven can hold?
Different models hold different amounts of shelves like 1, 2, 3, 4, 5 shelves. That will be according to the models.
2. What is your max temperature?
Max 300 degree C, 250degree C is normal.
3. What kind of size do you have?
We have 40L(1.4 cuft), 72L(2.5 cuft), 151L(5.3 cuft) and 393L (13.8 cuft). They are normal and popular models. If you need bigger size we can supply it too.
4. Can you make 110V versions?
Yes, we can make it.If you have any needs of lab instruments, please feel free to email us. Thank you~
