Snake Venom Vacuum Freeze Dryer

                                     Snake Venom Vacuum Freeze Dryer                           Is your specification u are looking for?1) Laboratory freeze dryer
2) Sealing strong
3) Accurate data
4) Stable performanceProduct DescriptionWhy choose our products?1.Accord with international standards of Green environmental friendly.2. 7" True-color Touch Screen, Chinese English Bilingual Interface, display drying curve and history curve;3. long-term storage and remain cells active.4. Upload software can print curve;5. Embedded circuit design, 128 M FLASH, can save dozen times Lyophilized data;6.Large opening trap, no coil inside, with samples pre-freeze function.7. Imported refrigeration compressor, low noise.8. Cold trap and control panel were made by stainless steel, corrosion-resistant, easy to clean.9. Transparent Bell type drying room, secure and ocular.10. Stainless steel sample holder, common sample plate spacing adjustable.11. Small size and easy to operate.12. Nitrogen inflation valve within. Want to know more details?  Technical data of laboratory freeze dryer:

Scientz-18ND	Ordinary	Top-Press	Ordinary Multi-Manifolds	Top-Press Multi-Manifolds
No-load  Temperature	<-56℃	<-56℃	<-56℃	<-56℃
Freeze Area	0.18 m2	0.09 m2	0.18 m2	0.09 m2
Plate Load  Capacity	2 L	1 L	2 L	1 L
Ability to  Capture Water	6Kg	6Kg	6Kg	6Kg
Vacuum Degree	<10Pa	<10Pa	<10Pa	<10Pa
Machine  Dimension(mm)	W700×D560 ×H(960+450)	W700×D560 ×H(960+450)	W700×D560 ×H(960+450)	W700×D560 ×H(960+450)
Sample Tray  Size	4×Φ240mm	Ø 3×200 mm	4×Φ240mm	Ø 3×200 mm
Power	1300W	1300W	1300W	1300W
Power Supply	110V/60Hz or  220V/50Hz	110V/60Hz or  220V/50Hz	110V/60Hz or  220V/50Hz	110V/60Hz or  220V/50Hz
interlayer  spacing	70 mm	70 mm	70 mm	70 mm
Cold trap size	Ø270×410 mm	Ø270×410 mm	Ø270×410 mm	Ø270×410 mm
The number of Schering bottles	Ø22: 360	Ø22: 270	Ø22: 360	Ø22: 270
	Ø16: 740	Ø16: 560	Ø16: 740	Ø16: 560
	Ø12: 1320	Ø12: 990	Ø12: 1320	Ø12: 990

Packaging & ShippingHow to be packaged?
-Export wooden or carton packing
-Both neutral and customized packaging can be availableShipping of laboratory freeze dryer
-We can ship the goods to you per the below shipping methods and you can choose the appropriate one
based on your timeline and budget. Also you can definitely choose to use your own shipping agent. Company Information Why choose KD?
Zhengzhou Keda Machinery and Instrument Equipment Co.,Ltd. is a pharmaceutical equipment
integrated company, highly specialized in R&D, production, especially Intelligent PID
Temperature Controller, Double Layer Chemical Glass Reactor, Single Layer Glass Reactor,
and lab crystallizer equipment. widely used in production of cosmetics, display of
university teaching, chemical and biological purification.
Company Tanet: Keeping good reputation, Valuing contracts, beniefiting customers from satisfying price and high quality, we always follow this principle.
Factory Size: 1,000-3,000 square meters
Year Established: 2009
Total Revenue : US$1 Million - US$2.5 Million
Registration No.: 410105000067362  Our Services Warranty & Service
1. One year warranty service after the product was sold.
2. In the warranty period,if meet problems,you will enjoy maintain free of charge.
3. Beyond the warranty period,charge component cost and maintenance cost properly.
4. Please read the product manual carefully before using this product. Operating the
product strictly according to the operation method.
5. any problems you meet, pls contact us by telephone or email, provide you best
consulting, maintenance and other services in time.
Tel: +86-371-53780197
Fax: +86-371-60920178
http://www.kdinstrument.com/
http:///FAQ 1.What's the minimum order quantity?One set at present. 2.What kind of payment term do you accept?Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal. 3. How will you delivery these goods?It will be decided according to your quantity. Normally we will choose International Express,  Air and sea. 4.How will package glass equipment?We package these glass equipment in good and Non fumigation standard wooden case. 5.Can you accept OEM terms?Sure.Hot line:(86)0371-86126825(24h)
Mobile phone:13783441102
The price can be negotiable,
For more details about laboratory freeze dryer please contact us we will reply to you within 24 hours,any inquiry is warmly welcomed!Snake Venom Vacuum Freeze DryerSnake Venom Vacuum Freeze DryerSnake Venom Vacuum Freeze Dryer

Contact us if you need more details on Northstar Freeze Dryer. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Snake Venom Vacuum Freeze Dryer、Vacuum Freeze Dryer. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Drying Machine Series > Freeze Dryer
