Vertical automatic Powder Packaging Machine 520

  • Vertical automatic Powder Packaging Machine 520
  • Vertical automatic Powder Packaging Machine 520
  • Vertical automatic Powder Packaging Machine 520
  • Vertical automatic Powder Packaging Machine 520

Vertical automatic Powder Packaging Machine 520

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CFR,CIF,EXW
    Min. Order: 1 Set/Sets
    Delivery Time: 30 Days
    Packaging: wooden case
    Transportation: Ocean
    HS Code: 8422303090
    Port: Qingdao

Basic Info

Model No.: GQF-520

Product Description

Product Description

1. The units: a. GQ-520 Main machine
b. Screw metering device
Alternative: c. Spiral Feeding Machine
d. Product conveyor
Applications:Milk powder, protein powder, cocoa powder, soft sugar, glucose powder, dye, food additives, flavors and so on.
2. The unit’s technical parameters:
a. Packing speed: 20-60bags/min, packing speed depend on the packaging quality and material.
b. Bag size: w: 60-250mm, l: 50-350mm,
Different film width needs different shaper, the length can be adjusted within a limited scope
c. Bag making type: roll film for packaging materials, the bags can be seal at the top, the bottom, and the back side, easy to tear the mouth or flat, a date printing device.
d. Total power: 3.8kw
e. Air consumption: ≥1m3 (the buyer purchase) stere
The buyer needs to purchase the nitrogen machine, the Packaging Machine has been with gas source when leaving the factory
f. total height: 3.5m
3. Different parts:
a. GQ-520 vertical automatic packaging machine


①.Characteristics: *Imported PLC computer control system with human-machine inter face;
touch screen is simple and direct-viewing in operation;
Precise positioning with servo film transporting system; excellent complete machine performance and nice packing;
* Minimize the loss with complete automatic warn protection function;
*supported with metric device, the machine will automatically complete all packaging processes from measuring, feeding, filling, date printing;
*The way of bag making: the machine can make pillow-type bags, vertical angle bags and hanging bags according to customer’s requirements
②. Technical parameter:

Items
Content
Packing speed
5-80 bag/min
Bag size
(L)50-350mm (W)60-250mm
Bag making mode
Pillow-type bag, standing bag, punch
Filling Range
150- 1500ml
Thickness of film
0.04-0.08mm
Air consumption
200L/min 0.7*105MPa
Main power/voltage
2.2KW/220V 50-60Hz
Dimension
1400×970×1600mm
The weight of switchboard
300kg

③Electrical configuration

Name
Brand
Country
Touch sensitive screen
WEINVIEW
TAIWAN
PLC
MITSUBISH
JAPAN
Servo motor and driver
SIEMENS
GERMAN
Transducer
HUICHUAN
SHENZHEN
Horizontal cylinder
SMC
JAPAN
Vertical cylinder
SMC
JAPAN
Cutting cylinder
SMC
JAPAN
Electromagnetic vale
JINQI
TAIWAN
Paper Photoelectric eye
BAIDELI
TAIWAN
Solid state relay
YANGMING
TAIWAN
Intermediate state relay
OMRON
JAPAN
Thermometer control
YA TAI
SHANGHAI
Blanking photoelectric eye
PS-DSION
KOREA
Code printer
TIANYI
Xiamen
Power
MW
TAIWAN

b. Screw metering device

①.Performance Characteristics: *Simple structure, reliable operation, maintenance is simple and
convenient.

*The screw machine adopts a rotary screw feeding, servo encoding, microcomputer control technology. It has many characteristics, such as encoding control in one, sensitive, low noise, stable, reliable, fast measuring speed, high precision etc. We also used a composite hopper which is convenient to clean up.
②. Technical parameters:

Project
Content
Packing speed
5-80 bag/min
Bag size
(L)50-300mm (W)60-200mm
Type of bag making
Pillow bag, vertical angle bag, punching device
Measuring range
150-1500ml
The film thickness
0.04-0.08mm
Gas consumption
200L/min 0.7×105Pa
The total power / voltage
2.2KW/220V 50-60Hz
Appearance size
1400×970×1600mm
The switchboard weight
300kg

c. The spiral feeding machine

①.Product Description: This machine adopts screw feeder and vibration hopper. Suitable for conveying all kinds of powder and granule materials
②. Technical parameters: weight: 100Kg

Lifting height (standard)
2.35m
Lifting capacity
3 cubic meters / hour
Specifications
According to customer requirements
Material
Production according to customer requirements

d. Product conveyor

Introduction
The machine can automatically send the packed finished bag after - package detecting device or packing platform
Technical parameters
Transmission speed: 30 m / min.
Dimensions: 2110 x 340 x 500mm
Voltage: 220V/45W weight: 30Kg


Our Company

Jinan GUO QIANG Machinery Equipment CO.LTD adhere to the specialization, scale, standardization of the road in the field of packaging machinery, and regard “to do Chinese best packaging machine manufacturers” as the management goal. We provide five star product and service for the customer to reduce packaging costs, and improve enterprise benefit. We put “let the packaging even more perfect, more customer satisfaction” as our basic requirement of service concept, put forward the “heart” service, for customers to think more, do better than the peers

Our Service

Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.

After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.

Packing & Delivery


Packaging Details:
Wooden case


Delivery Detail:
Shipped in 25 days after payment
